Recommended horsepower rating: 750-1250HP
Recommended engine displacement: 2.5L to 7L
Dual Ceramic Ball Bearing
This is an oil cooled turbo charger
Billet aluminium 7 + 7 compressor wheel.
Ported shroud compressor housing cover.
Speed sensor port included in compressor cover.
(Sold separately AF8050-1010)
External wastegate sold seperately.
1/4NPT turbo oil feed fitting.
Recommended turbo drain adapter AF463-02 or AF463-06.
V-band sold seperately
Turbine inlet flange gasket sold separately AF9557-0003
Compressor:
Inducer - 80.3mm
Exducer - 113mm
Extended Tip - 117.36mm
A/R -
Inlet - 5"
Outlet - V Band
Turbine:
Inducer - 83.65mm
Exducer - 75mm
A/R - 1.10
Inlet Flange - T4
Outlet Flange - V Band
Wastegate - External
