Recommended horsepower rating: 250-445HP
Recommended engine displacement: 1.8L to 3L
Dual ceramic ball bearing
Billet aluminium compressor wheel
Ported shroud compressor housing cover
Speed sensor port included in compressor cover (sold separately, AF8050-1010)
Inlet flange single layer gasket, turbo drain gasket and -4AN turbo oil feed fitting with restrictor included in turbo kit
Turbine inlet gasket sold separately AF9557-0001
Recommended turbo drain adapter AF463-01 or AF463-05
M14x1.5mm coolant fittings sold separately
Compressor
Inducer: 54mm
Exducer: 71mm
Extended Tip: 73.79mm
A/R: 0.60
Turbine
Inducer: 53.9mm
Exducer: 47mm
A/R: 0.86
Compressor Inlet: 3" Slip fit
Compressor Outlet: 2" Slip fit
Turbine Inlet Flange: T25 / T28
Turbine Outlet Flange: 5-Bolt
Wastegate: Internal wastegate with 8.7psi actuator
