NISSAN SR20 GTIR AWD SINGLE STAGE EXTERNAL OIL PUMP SETUP
This kit includes the following:
- Nissan SR20 GTiR AWD Harmonic Damper with optional 12 or 36-2 Tooth Integrated Trigger Disc
- Integrated 12T & 36T Crank Triggers available off the shelf, please contact us for custom profiles
- Trigger profiles cut using micron accurate EDM wire cutting technology to ensure a clean signal for ignition timing
- Bonded using our proprietary Ross Tuffbond process, incorporating anti-vibration, anti-tear natural rubber
- Laser etched 360º timing marks
- Nissan SR20 RWD / GTiR AWD Oil Pump Left Hand Mounting Bracket (304001-18)
- Nissan SR20 Oil Return Adaptor (Remote Oil Filter Set-up) (304001-25-1)
- Universal Dry Sump Drive Adaptor with 19T HTD Pulley (991000-19HTD)
- 38T HTD Oil Pump Pulley with Pulley Shields (991038)
- 8mm HTD Oil Pump Drive Belt – 576mm x 20mm (993576-8M-20)
- Aviaid Single Stage External Oil Pump – LH Mounting with 1 x 1.5” Pressure (9950110-3800)
Note: The External Oil Pump Mounts in the OEM air conditioner location. A/C Must be removed to install this setup.
