OCAM Deluxe Steel Bull Bar For Isuzu D-MAX 08/2020-04/2024 & OCAM 12k Winch

OCAM Bull Bar For Isuzu D-MAX 08/2020-04/2024
Heavy Duty Steel ADR Compliant, OCAM 12k Winch
WARRANTY: 2 YEARS

Are you looking to install a full-protection bull bar on your 4WD? Good decision! With over 50 million kangaroos roaming across Australia (est. 2022), the need for protection is greater than ever. Installing a full-protection bull bar not only enhances off-road capability but makes driving much safer, especially in rural areas. In the event of an animal strike, a bull bar can protect vital components like your radiator, allowing you to continue driving instead of being stranded and in need of a tow.

The OCAM Deluxe Bull Bar is a premium product designed to match the shape of your vehicle, enhancing both protection and appearance. It also provides a solid mounting structure for essential off-road accessories like winches, driving lights, and UHF antennas.

MANUFACTURING
OCAM bull bars are manufactured overseas using high-quality materials. Our appointed OEM facility adheres to strict quality control processes, ensuring you receive a durable, reliable product.

CRASH TESTING / ADR COMPLIANCE
Our bull bars are crash-tested in Australia and ADR compliant, with a patent-pending energy-absorbing system that offers market-leading protection.

RECOVERY POINTS
Integrated factory recovery points are rated to 3400 kgs when used with an equalizer strap, saving you the cost of finding additional recovery solutions.

POWDER-COATING
The OCAM bull bars go through a rigorous 4-stage powder-coating process:

1. Pre-treatment: Metal is cleaned, phosphatized, and protected.
2. Cathodic epoxy electrocoating: Provides superior adhesion and corrosion resistance.
3. Prime Powder Coat: Fixes surface imperfections and reinforces corrosion protection.
4. Top powder coat: Adds a final layer for ultra-reinforced corrosion protection and a smooth finish.

STRENGTH
The bar uses a 63mm top tube and is 100% welded with 2.5mm plate bar and reinforcement plates for added strength.

DELUXE VALUE
Equipped with LED turn signals, parking lights, and daytime running lights, all OCAM bull bars come with LED fog lights at no extra cost, plus 3 top tube mounts and 2 high-lift jack points. These bull bars are winch-compatible and include a number plate flip mount.

FEATURES

• Modern energy absorber system (Patent-Pending)
• Winch compatible
• Heavy-duty steel construction
• Robot-welded for precision manufacturing
• Latest LED design with dual brightness fog lights, parkers, and indicators
• SRS airbag tested and ADR approved
• High-grade black e-powder coat for long-lasting rust protection
• Underbody skid-protection plates
• Polyurethane protection bumpers
• 63mm top tube with aerial/light mounting brackets
• 2 high-lift jack points
• 2 recovery points, rated to 1700 kgs each (total 3400 kgs with equalizer strap)
• Number-plate swivel bracket
• Complete mounting kit with instructions

FITTING
We offer complete fitting services at OCAM locations across Australia. For a quote, please provide your postcode and suburb, and we'll confirm pricing.

OCAM Premium Electric Winch (5443KGS / 12000LBS)
26M Synthetic Dyneema® SK-75 Rope, Wireless Remote, 4WD 12V
WARRANTY: 4 YEARS

The OCAM Premium Winch features a powerful 6.6 HP IP68-rated motor, heavy-duty casing, and genuine Dyneema® SK-75 synthetic rope. Backed by a 4-year warranty, it provides reliable pulling power for most winch-compatible bull bars in Australia.

Product Highlights:

• Tough on and off-road ability
• Reliable in harsh weather and resistant to corrosion
• Dual remote modes: wired and wireless function

Why choose Dyneema® SK-75 synthetic rope over steel cable?

• Over 1.5X stronger
• Less than 15% of the weight of steel
• At least 7X stronger when comparing weight to weight
• It floats in water
• The UHMwPE (Ultra-High Molecular weight Polyethylene) fibres are stronger than steel with high abrasion and friction-resistance.
• Should the rope break during recovery, synthetic is much safer. Unless a steel cable is dampened, the build-up of force will inevitably spring back on breaking. Whereas, the "very low" stretch properties of Dyneema® SK-75 means it will just fall rather than spring back. Synthetic rope can be respliced and recovery can continue, which is impossible with steel.
• It reduces the weight of your vehicle's front-end by at least 10KG
